Siemens SIMATIC TP1500 Comfort Outdoor User Manual

TP700 Comfort Outdoor, TP1500 Comfort Outdoor
14 Compact Operating Instructions, 05/2016, A5E35956909-AC
Mounting and connecting the HMI device
3
3.1
Preparing for installation
3.1.1
Checking the package contents
Check the package content for visible signs of transport damage and for completeness.
Note
Damaged parts
A damaged part will cause the HMI device to malfunction.
Do not install parts damaged during shipment. In the case of
damaged parts, contact your
Siemens representative.
Check the scope of supply of the HMI device (see Scope of delivery (Page 9)).
Additional documents may be included in the delivery.
The documentation is part of the HMI device and is required for subsequent commissioning.
Keep all enclosed documentation for the entire service life of the HMI device. You must pass
along the enclosed documentation to any subsequent owner or user of the HMI device.
Make sure that every supplement to the documentation that you receive is stored together
with the operating instructions.

Siemens SIMATIC TP1500 Comfort Outdoor Specifications

General

Display Size	15 inch
Brightness	1000 cd/m²
Power Supply	24 V DC
Memory	12 MB user memory
Display Type	TFT
Touchscreen	Yes
Storage Temperature	-30°C to +70°C
Weight	7.5 kg
Interfaces	USB
Protection Class	IP66
