Description
2.4 How do you determine the replacement encoder?
Replacing an encoder for SIMOTICS S-1FK7 G2, S-1FG1 and S-1FT7
28 Service Manual, 01/2018, A5E34676237B AC
Encoder without DRIVE-CLiQ interface, round plug connector M23
Encoder type, replaceable
For motor
Designation
Article number
Incremental encoder sin/cos
1 Vpp 2048 S/R
Motor Article number
:
1FK7□□□-□□□□□-□
A
□□
1FG1□□□-□A□□□-□□□□
1FK703/1FG1□□□-□□C
IC2048S/R-72
6FX2001-3JC04-1QA0
1FK704/1FG1□□□-□□D
1FK706/1FG1□□□-□□E
1FK708/1FG1□□□-□□F
1FK710/1FG1□□□-□□G
IC2048S/R-88 6FX2001-3JC04-1DA0
Absolute encoder 2048 S/R
EnDat
Motor Article number
:
1FK7□□□-□□□□□-□
E
□□
1FG1□□□-□E□□□-□□□□
1FK703/1FG1□□□-□□C AM2048S/R-
72
6FX2001-5JE04-1QA0
1FK704/1FG1□□□-□□D
1FK706/1FG1□□□-□□E
1FK708/1FG1□□□-□□F
1FK710/1FG1□□□-□□G
AM2048S/R-
88
6FX2001-5JE04-1DA0
You have found the appropriate encoder.
❒
Based on the determined encoder Article number, you can directly order an encoder that has
not been written to (not loaded with data).
If you wish to order an encoder loaded with the data associated with the motor, then you
must change the last position of the Article number to "1".
Example: "6FX2001-☐☐☐☐☐-☐☐☐
0
" → "6FX2001-☐☐☐☐☐-☐☐☐
1
"
Once you have selected the appropriate encoder, enter an order as described in Chapter
"How do you order a replacement encoder? (Page 29) ".
