2.8 How do you backup the data of the electronic type plate?
Replacing an encoder for SIMOTICS S-1FK7 G2, S-1FG1 and S-1FT7
Service Manual, 01/2018, A5E34676237B AC
45
2.8
How do you backup the data of the electronic type plate?
The electronic type plate data are saved to the drive. The electronic type plate is required to
program an encoder module that has not been loaded with data.
Requirements for saving the data on the electronic rating plate
● SINAMICS firmware as of version 2.5 must be installed.
● The commissioning procedure must have been completed. All component numbers must
be less than 200.
Note
From SINAMICS SW 4.3 / SINUMERIK
-SW 4.4, encoder data are automatically backed up
when commissioning.
You can find the data in directory: /user/sinamics/data/smi_data. The backup
folder is
designated with c012 (12=comp.no.).
The backup folder contains:
•
For DQI encoders, file "dqixe1.bin" (motor data)
•
For encoders with SMI, files "smi20xe1.bin" (motor data) and "smi20xe2.bin" (encoder
data)
You only have to save the motor and encod
er data as subsequently described if you found
no motor and encoder data from the defective encoder in the drive.
