Introduction
Replacing an encoder for SIMOTICS S-1FK7 G2, S-1FG1 and S-1FT7
4 Service Manual, 01/2018, A5E34676237B AC
What is shown and how?
Notes
Notes are shown as follows:
Note
A Note is an important item of information about th
e product, handling of the product or the
relevant section of the document. Notes provide you with help or further suggestions/ideas.
In addition to the notes that you must observe for your own personal safety as well as to
avoid material damage, in this document you will find the following text features:
An instruction with a specified sequence starts with the subtitle:
The individual handling steps are numbered.
1. Execute the operating instructions in the specified sequence.
A square at the end of the final sentence indicates the end of a specific instruction.
❒
Operating instructions without a specified sequence are identified using a bullet point:
● Execute the operating instructions.
● Enumerations are identified by a bullet point without any additional symbols.
– Enumerations at the second level are hyphenated.
Links to additional information are underlined in blue.
When passing over the link, the mouse pointer changes to a hand symbol.
Where can I find additional information?
Information on the following topics is available at:
● Ordering documentation / overview of documentation
● Additional links to download documents
● Using documentation online (find and search in manuals / information)
More information (https://support.industry.siemens.com/cs/de/en/view/108998034)
If you have any questions regarding the technical documentation (e.g. suggestions,
corrections), please send an e-mail to the following address E-mail
(mailto:docu.motioncontrol@siemens.com).
