Technical Data
5.2 Technical data for D445
Connection values
Table 5-6 Electrical connection values
parameters Value range
Supply voltage VDC (permissible range: 20,4 ... 28.8 V)
Power consumption from 24 V Typical power consumption: 2 A
(with no load at inputs/outputs, no supply from
DRIVE CLiQ I/O or PROFIBUS)
Power loss 15 W
Starting current 6 A
Dimensions and weight
Table 5-7 Dimensions and weight of a D445
parameters Values
Dimensions W x H x D [mm]
Without mounting and fan/battery module With
mounting and fan/battery module
(max. expansion)
50x420x272
50x420x272
Weight of SIMOTION D445 [g] Approximately 3600
Weight of SIMOTION CF [g] 7
Ambient conditions
Table 5-8 Environmental requirements
parameters Values
Permissible ambient temperature
Storage and transport
Operation
-40°C...+70°C
0°C...+55°C
Permissible relative humidity
(without condensation)
5% ... 95%
Air pressure 700 hPa...1060 hPa
Degree of protection according to IEC 529 IP20
D4xx
Manual, 12.2004, 6AU1900-1AJ32-0BA0
5-3
