Spare parts/accessories
7.7 CX32 module
7.7 CX32 module
Features of the CX32 (Control Extension)
The CX32 module enables you to expand the performance of a SIMOTION D axis assembly.
The number of connectable axes is increased.
The CX32 has the following interfaces:
• 4 DRIVE CLiQ (X100 – X103)
• 4 digital inputs and 4 digital inputs/outputs (X122)
• Power supply (X124)
Additional references
You can find additional information about the CX32 in the SINAMICS S120 product manual
and the SINAMICS S120 commissioning manual.
Caution
The 80 mm clearances above and below the components must be observed.
D4xx
7-8 Manual, 12.2004, 6AU1900-1AJ32-0BA0
