● Digital inputs (DI)
●
Bidirectional digital inputs/outputs (DI/DO)
Bidirectional digital I/Os can be configured individually as digital inputs or outputs.
Assignment of the I/Os to functions can be parameterized as required. Special functions (e.g.
input of the measuring input) can be assigned to the I/Os.
The digital inputs/outputs on the X122 front connector can be used by either SIMOTION or
SINAMICS (e.g. as enable signal for a drive).
Table 7-24 Use of the digital inputs/outputs
DI 0-3, DI 16, DI 17 (X122) DI/DO 8-11 (X122)
Galvanic isolation Electrically isolated
(ground reference M1)
Non-isolated
(ground reference M)
Use as:
● Freely
addressable I/Os
for SIMOTION
yes yes
● I/Os
that are assigned to
the drive
yes yes
● Measuring inputs no Yes
(global
and local measuring inputs)
● Inputs for the external
zero mark
no yes
● Cam outputs no no
Configuration:
Assignment Can be configured channel-by-
channel on the drive
Can be configured channel-by-
channel on the drive
Note
For optimal noise immunity of the digital inputs, the use of shielded cables is necessary in
certain cases. This is necessary when the digital inputs are to be used as
●
Inputs of measuring inputs or
● Inputs for the external zero mark
Additional references
For information on configuring the I/Os as freely addressable I/Os or as measuring inputs, see
the
SIMOTION D4x5‑2
Commissioning and Hardware Installation Manual.
For information on the configuration and function of the measuring input, output cam, and cam
track technology objects, see the
SIMOTION Output Cams and Measuring Inputs
Function
Manual.
Supplementary system components
7.5 CX32-2 controller extension
SIMOTION D4x5-2
Manual, 04/2014 123
