Integrated drive control
Table 7-31
Controls for integrated drives
Data SIMOTION CX32‑2
Max. number of axes for integrated drive control
(servo/vector/
V
/
f
)
6 / 6 / 12 (alternative)
drive control based on SINAMICS S120 CU320‑2,
firmware version V4.x
Communication
Table 7-32
Interface communication
Data SIMOTION CX32‑2
DRIVE‑CLiQ interfaces 4
General technical data
Table 7-33
Technical data (general)
Data SIMOTION CX32‑2
Power supply
●
Rated value
● Permissible range
24 V DC
(20.4 ... 28.8 V)
Current consumption, typically
1)
300 mA
Starting current, typical 1.6 A
Power loss, typical 7 W
Power loss, max. 14 W
1)
With no load on inputs/outputs, no 24‑V supply via DRIVE‑CLiQ interface
Digital inputs
Table 7-34
Digital inputs on SIMOTION CX32‑2
Data SIMOTION CX32‑2
Digital inputs 6
● Rated value 24 V DC
● For signal "1" 15 ... 30 V
● For signal "0"
2)
-3 ... +5 V
Galvanic isolation Yes, in groups of 6
1)
Current consumption typ. at High level 9 mA at 24 V
Input delay, typical (hardware) Signal "0" → "1": 50 µs
Signal "1" → "0": 150 µs
1)
The reference potential is terminal M1
2)
The digital inputs are protected against polarity reversal up to -30 V
Supplementary system components
7.5 CX32-2 controller extension
SIMOTION D4x5-2
128 Manual, 04/2014
