Data SIMOTION D4x5-2 DP SIMOTION D4x5‑2 DP/PN
PROFIBUS interfaces
1)
2 2
PROFINET interfaces
2)
--- Onboard:
1 interface with 3 ports
Optionally:
Second interface with 4 ports via
CBE30‑2
1)
Supports PROFIBUS DP, isochronous, can be configured either as master or slave
2)
Supports
PROFINET IO with IRT and RT, can be configured as PROFINET IO controller and/or device
Address space
Table 5-13 Address space
SIMOTION D4x5-2 DP SIMOTION D4x5-2 DP/PN
Logical I/O address space 16 KB 16 KB
Physical I/O address space for each
interface,
one each for inputs and outputs
● PROFIBUS
● PROFINET
● 1 KB
1)
● 1 KB
1)
● 4 KB
1) 2)
Permanent process image for
BackgroundTask (I/O variables)
64 bytes 64 bytes
Additional configurable process image
for each cyclic task (I/O variables)
yes yes
Address space for each PROFIBUS DP
station
244 bytes 244 bytes
Address space for each
SINAMICS Integrated/CX32-2
(PROFIBUS Integrated)
512 bytes 512 bytes
Address space for each PROFINET
device
--- 1,400 bytes
Maximum consistency range
Onboard PROFINET interface X150
●
For controller-controller peer-to-
peer communication
● For I‑Device
---
254 bytes
1024 bytes (as of V4.4)
254 bytes (< V4.4)
CBE30‑2
●
For controller-controller peer-to-
peer communication
● For I‑Device
---
254 bytes
254 bytes
1)
When
PROFIBUS and PROFINET are used, the total address space applies: All I/O are assigned in
the logical I/O address space. The maximum number of I/Os is limited by the number that can be
addressed using the logical I/O address space.
2)
A second PROFINET interface for the D4x5‑2 DP/PN Control Units is optionally available for the
CBE30-2.
Technical data of the D4x5-2
5.5 Interfaces and performance features
SIMOTION D4x5-2
84 Manual, 04/2014
