Siemens SINUMERIK 802D sl - ISO Dialect Milling Addresses

Notes
SINUMERIK 802D sl Operating and Service Training Manual Page 5
C95
C95
Section 4
ISO Dialect milling addresses
4.1 ISO Dialect milling addresses
Address Meaning
F
Feed G94 (mm/inch per min)
F
Feed G95 (mm/inch per rev)
F Thread
pitch
C Chamfer
R Radius
Q
I, J, K
Interpolation parameters
X
G4 Time unit
A Contour
Angle
These are the different addresses that are used in ISO dialect.
