2.3 Notes on the PLC interface signal address representation
Currently, PLC interface signal addresses are represented by the V structure on the HMI while
the manual shows them by the DB structure.
See the following table for the relationship between the two representations.
V Structure DB Structure
Access Example Example Access
Bit V38000002.1 DB3800.DBX2.1 Bit
Byte VB38000002 DB3800.DBB2 Byte
Word VW38000002 DB3800.DBW2 Word
Double Word VD38000004 DB3800.DBD4 Double word
