Introduction
2
2.1 Structure of the Diagnostics Manual
Alarms
The descriptions for the alarms can be found in the chapters:
●
NCK alarms
(Page 47)
● Cycle alarms (Page 363)
● Drive alarms (Page 509)
● PLC alarms (Page 521)
● PLC user alarms (Page 527)
● SINAMICS V70 faults and alarms (Page 535)
In each chapter, the alarm descriptions are sorted according to ascending alarm number. There
are gaps in the sequence.
Structure of the NCK/cycle/drive/PLC alarm descriptions
The descriptions of the alarms have the following layout:
Each alarm is uniquely identified using the <Alarm number> and the <Alarm text>.
The description of the alarms is classified according to the following categories:
● Explanation
●
Reaction
See Chapter: System reactions to SINUMERIK alarms (Page 529)
● Remedy
● Program continuation
See Chapter: System reactions to SINUMERIK alarms (Page 529)
