Operating and Programming — Milling Page 110 808D
Appendix
s
Group 3: Programmable frame
Name Meaning
TRANS Translation
ROT Rotation
SCALE Programmable scaling factor
MIRROR Programmable mirroring
ATRANS Additive translation
AROT Additive programmable rotation
ASCALE Additive programmable scaling factor
AMIRROR Additive programmable mirroring
G110 Pole specification relative to the last programmed setpoint position
G111 Pole specification relative to origin of current workpiece coordinate system
G112 Pole specification relative to the last valid POLE
Group 6: Plane selection
Name Meaning
G17 * X/Y plane
G18 Z/X plane
G19 Y/Z plane
Group 7: Tool radius compensation
Name Meaning
G40 * Tool radius compensation OFF
G41 Tool radius compensation left of contour
G42 Tool radius compensation right of contour
Group 8: Settable zero offset
Name Meaning
G500 * Settable work offset OFF
G54 1st settable zero offset
G55 2nd settable zero offset
G56 3rd settable zero offset
G57 4th settable zero offset
G58 5th settable zero offset
G59 6th settable zero offset
Group 9: Frame suppression
Name Meaning
G53 Non-modal skipping of the settable work offset
G153 Non-modal skipping of the settable work offset including base frame
Group 10: Exact stop — continuous – path mode
Name Meaning
G60 * Exact positioning
G64 Continuous — path mode
Group 11: Exact stop, non-modal
Name Meaning
G09 Non-modal exact stop
Group 12: Exact stop window modally effective
Name Meaning
G601 * Exact stop window
G602 Exact stop window, course, with G60, G9
