Operating and Programming — Milling Page 62 808D
Machine
Pieces
s
SEQUENCE
“Cycle timeshows how long the pro-
gram has been running.
“Time left” shows how much time re-
mains before the program ends.
Step 2
Select “Yes” or “No” to decide whether
to activate the counter (press the
“Select” key to activate the choice).
Enter the number of workpieces you
require to be machined in “Required”.
Machine
Pieces
Make sure that only “AUTO” mode and
“ROV” mode are activated
(or select the M01 function if required).
Make sure that the feedrate override on the MCP is 0%!
Press “Door” on the MCP to close the door of the
machine. (If you don’t use this function, just close
the door on the machine manually.)
Turn the feedrate override gradually to the required value.
“Actual” shows the number of workpiec-
es that have been machined.
The “Time left” can only be counted after a suc-
cessful cycle run of a part program!
Make sure the program is correct before
machining pieces!
Press “CYCLE START” on the MCP to execute the program.
Set the program in
the ready-to-start
status as shown on
the left in accord-
ance with the
“Program execu-
tion” sequences.
Perform the
relevant safety
precautions
NotesM01 function program will stop at the
position where there is M01 code.
