Operating and Programming — Milling Page 92 808D
Sample
Program
s
N430 SUPA G00 Z300 D0
N440 SUPA G00 X300 Y300
; ======Contour milling start======
N450 T2 D1
N460 MSG ("Please change to Tool No 2")
N470 M05 M09 M00
N480 S5000 M3
N490 CYCLE72( "CONT1:CONT1_E", 50, 0,
2, -5, 5, 0, 0, 300, 100, 111, 41, 12, 3,
300, 12, 3 )
; ======Contour milling end=======
N500 SUPA G00 Z300 D0
N510 SUPA G00 X300 Y300
; =Rectangular pocket milling start==
N520 T2 D1
N530 MSG ("Please change to Tool No 2")
N540 M05 M09 M00
N550 S6500 M3
N560 POCKET3( 50, 0, 1, -3, 40, 30, 6,
36, 24.1, 15, 3, 0.1, 0.1, 300, 300, 0, 11,
12, 8, 3, 15, 0, 2 )
N570 POCKET3( 50, 0, 1, -3, 40, 30, 6,
36, 24.1, 15, 3, 0.1, 0.1, 300, 300, 0, 12,
12, 8, 3, 15, 0, 2 )
; ==Rectangular pocket milling end==
N430
N440
; ======Contour milling start======
N450
N460 hint:change to tool 2
N470
N480
N490 contour cutting depth 5 mm, surface
machining feedrate 300 mm/min, cutting
direction feedrate 100 mm/min, use G41 to
activate compensation, use G1 to do rough
machining, back to the machining plane at the
end of the contour, approach path is along 1/4
circle in space, length 3 mm, the parameters of
feedrate//path/length for retraction and ap-
proach are equal.
; ======Contour milling end=======
N500
N510
; =Rectangular pocket milling start==
N520
N530 hint:change to tool 2
N540
N550
N560 milling rectangle groove (depth 3
mm, length 40 mm, width 30 mm, corner
radius 6 mm,groove base point coordinate
(X36,Y24.1), angle between groove verti-
cal axis and plane X axis is 15º), finishing
allowance 0.1 mm, feedrate surface
machining and cutting direction machining
is 300 mm/min, milling in positive direction,
rough machining, use G1 vertical groove
center to insert.
N570 repeat N600 milling process, the
difference is the machining allowance.
; ==Rectangular pocket milling end==
N270 SUPA G00 Z300 D0
N280 SUPA G00 X300 Y300
N290 T4 D1
N300 MSG ("Please change to Tool No 4")
N310 M05 M09 M00
; ===Circular pocket milling start====
N320 S5000 M3
N330 POCKET4( 50, 0, 2, -5, 22, 38, 70,
2.5, 0.2, 0.2, 300, 250, 0, 21, 10, 0, 5, 2,
0.5 )
N340 S5500 M3
N350 POCKET4( 50, 0, 2, -5, 22, 38, 70,
2.5, 0.2, 0.2, 250, 250, 0, 22, 10, 0, 5, 2,
0.5 )
; ===Circular pocket milling end====
N360 SUPA G00 Z300 D0
N370 SUPA G00 X300 Y300
N380 T5 D1
N390 MSG ("Please change to Tool No 5")
N400 M05 M09 M00
; ========Slot milling start========
N410 M3 S7000
N420 SLOT2( 50, 0, 2, , 3, 3, 30, 6, 38,
70, 20, 165, 90, 300, 300, 3, 3, 0.2, 0, 5,
250, 3000, )
; ========Slot milling end========
N270
N280
N290
N300 hint:change to tool 4
N310
; ====Circular pocket milling start===
N320
N330 milling circular groove（depth 5
mm, radius 22 mm, groove center coordi-
nate (X38,Y70), finishing allowance 0.2
mm, plane machining feedrate 300 mm/
min, depth machining feedrate 250 mm/
min, milling in positive direction, along
helical path insert to do rough machining,
helical path radius 2 mm, insert depth 0.5
mm）
N340
N350 repeat N370 milling process, the
difference is the machining allowance.
; ====Circular pocket milling end===
N360
N370
N380
N390 hint:change to tool 5
N400
; ========Slot milling start=======
N410
N420 milling slot（depth 3 mm, machin-
ing 3 slots, slot angle 30º, slot width 6
mm, basic circle center point coordinate
(X38,Y70), basic circle radius 20 mm,
start angle 165º, slot incremental angle
90º, depth machining feedrate 300 mm/
min, plane machining feedrate 300 mm/
min, milling direction G3, slot edge finish-
ing allowance 0.2 mm, complete machin-
ing ways, finishing machining feedrate 250
mm/min, spindle speed rate 3000 r/min
; ========Slot milling end=======
Machining Process
