Operating and Programming — Milling Page 94 808D
Sample
Program
s
Machining Process
This section is additional description
information created by system automati-
cally after finishing the programming of
the rough cutting CYCLE95 and does
not affect the system execution.
N1100 ;*************CONTOUR************
N1110 CONT1:
N1120 ;#7__DlgK contour definition begin -
Don't change!;*GP*;*RO*;*HD*
N1130 G17 G90 DIAMOF;*GP*
N1140 G0 X7 Y0 ;*GP*
N1150 G1 Y61.35 ;*GP*
N1160 G2 X13.499 Y86 I=AC(57) J=AC
(61.35) ;*GP*
N1170 G1 X63 RND=2 ;*GP*
N1180 Y0 ;*GP*
N1190 ;CON,0,0.0000,4,4,MST:0,0,AX:X,Y,I,J,
TRANS:1;*GP*;*RO*;*HD*
N1200 ;S,EX:7,EY:0;*GP*;*RO*;*HD*
N1210 ;F,LFASE:0;*GP*;*RO*;*HD*
N1220 ;LU,EY:61.35;*GP*;*RO*;*HD*
N1230 ;ACW,DIA:210/0,EY:86,AT:0,RAD:50;*
GP*;*RO*;*HD*
N1240 ;LR,EX:63;*GP*;*RO*;*HD*
N1250 ;R,RROUND:2;*GP*;*RO*;*HD*
N1260 ;LD,EY:0;*GP*;*RO*;*HD*
N1270 ;#End contour definition end - Don't
change!;*GP*;*RO*;*HD*
N1280 CONT1_E:;************* CONTOUR
ENDS ************
