Siemens SINUMERIK 840D Diagnostic Manual

Overview of Alarms 11/2006
NCK alarms
2-592
© Siemens AG, 2006. All rights reserved
SINUMERIK, SIMODRIVE Diagnostics Manual (DA), 11/2006 Edition
68000 Channel %1 block %2:
Parameters: %1 = Channel number
%2 = Block number, label
Definitions: References: The current alarm text, the error description and the remedial measures for the user cycle
alarms can be found in the Programming Guide of the machine manufacturer.
Reaction: Interpreter stop
NC Start disable in this channel.
Interface signals are set.
Alarm display.
NC Stop on alarm.
Remedy: Refer to the manual on user cycles.
Program
Continuation:
Clear alarm with the RESET key. Restart part program
69000 Channel %1 block %2:
Parameters: %1 = Channel number
%2 = Block number, label
Definitions: References: The current alarm text, the error description and the remedial measures for the user cycle
alarms can be found in the Programming Guide of the machine manufacturer.
Reaction: Interpreter stop
NC Start disable in this channel.
Interface signals are set.
Alarm display.
NC Stop on alarm at block end.
Remedy: Refer to the manual on user cycles.
Program
Continuation:
Clear alarm with the RESET key. Restart part program
70001 Channel %1 Yf is larger than distance C1-Cy
Parameters: %1 = Channel number
Definitions: In JOG mode, the Yf axis is traversed. The value of the Yf axis is larger than the distance C1-Cy
Reaction: Mode group not ready.
Channel not ready.
NC Start disable in this channel.
Interface signals are set.
Alarm display.
NC Stop on alarm.
Remedy: Traverse Yf axis in JOG mode in opposite traversing direction
Program
Continuation:
Clear alarm with the RESET key in all channels of this mode group. Restart part program.
70002 Channel %1 block %2 Yf has been programmed larger than distance C1-
Cy
Parameters: %1 = Channel number
%2 = Block number
Definitions: In the part program, one position in the Yf axis has been programmed larger than the distance C1-Cy
Reaction: Correction block is reorganized.
Local alarm reaction.
Interface signals are set.
Alarm display.
Remedy: Modify part program.
Program
Continuation:
Clear alarm with the RESET key in all channels of this mode group. Restart part program.
