B508 Page 6 840D/828D SINUMERIK Operate
Notes
The finishing of contours on the turned item can either be accomplished by
direct call-up of the contour subprogram or with the support of cycles.
The purpose of this document is particularly the variant of a direct call-up.
Note
For the sake of argument it is assumed that the work piece is already
loaded in the chuck on the finished diameter 70 mm and that the contour
has been roughed out with the usual finishing allowance.
For a subprogram call-up the following layout of the calling main pro-
gram is recommended:
1. Tool call-up followed by the statement of the technology data
2. Positioning at rapid traverse rate to the safety plane above the con-
tour starting point and simultaneously activation of the tool radius
correction
3. Call-up of the subprogram
4. Deactivation of the radius correction, possibly on the way to the tool
changing point
The editor printout below lets you follow through the entire program. (The
program section referring to the present problem starts at block N70)
N10 G18 G54 G64 LIMS=4000
N20 G00 X200 Z300
N30 T1 ; Roughing tool
N40 G96 S180 F0.25 M4 D1
N50 G00 X82 Z4 M8 ; Starting point for the roughing cycle
N60 CYCLE95("SUBR2",4,0.2,0.3,0,0.25,0.1,,1,0,0,3)
N70 G00 X200 Z300
N80 T2 ; Finishing tool
N90 G96 S220 F0.15 M4 D1
N100 G00 X0 Z2 G42 ; Starting point, radius correction ON
N110 SUBR2 ; Call-up of subprogram
N120 G00 X200 Z300 G40 ; Radius correction clear
N130 M30
Finishing with subprogram call-up
