840D/828D SINUMERIK Operate
Mirror, offset, rotate, scale
B510
1 Brief description
Aim of the module:
In this module you learn to offset the active work piece zero point in the program, scale the coordi-
nate system and insert dwells into the program sequence.
Description of the module:
This module describes the programmable manipulation of the coordinate system and the usage of
dwells.
