840D/828D SINUMERIK Operate
Operating area "Machine"
B519
1 Brief description
Aim of the module:
In this module you learn how to work with the different options of the operating area "Machine".
Description of the module:
In this module the basic menu is explained, with respect to each operating options. The basic menu
consists of a yellow horizontal softkey bar (with 6 operating areas) at the bottom and a yellow vertical
softkey bar (with 3 operating modes and 2 functions) at the right hand side of the screen. Depending
on the selected operation mode (“JOG”, “MDA”, “AUTO”) a different window option (HSK) and func-
tion option (VSK) is displayed in the operating area "Machine".
