Interruption point as search target:
1. - 2. Steps 1 and 2 (see above).
3. Press the VSK 6 “Interrupt point“
The interruption point is loaded.
4. If the VSK 3 "Higher level" and the VSK 4 "Lower
level" are available, use these to change the pro-
gram level.
5. Press the VSK 1 "Start search".
The search starts.
The specified search mode will be taken into ac-
count (indicated in the upper blue title bar of the
search target window).
The search screen closes.
The current block will be displayed and marked in
the "Program" window as soon as the target is
found.
6 Press the "CYCLE START"-key on the machine
control panel twice.
The execution will continue from the interruption
point.
Search target via search pointer:
1. - 2. Steps 1 and 2 (see above).
3. Press the VSK 7 “Search pointer”.
The “Search pointer” window opens.
4. Enter the full path of the program as well as the
subprograms, if required, in the input fields.
5. Press the VSK 1 “Start search”.
The search starts.
The specified search mode will be taken into ac-
count (indicated in the upper blue title bar of the
search target window).
The search screen closes.
The current block will be displayed and marked in
the "Program" window as soon as the target is
found.
6. Press the "CYCLE START"-key on the machine
control panel twice.
Processing is continued from the defined location.
Section 5
Block search
