840D/828D SINUMERIK Operate
840D/828D SINUMERIK Operate
Operating area “Program manager“
B525
1 Brief description
Aim of the module:
In this module you learn to handle programs and files in the program manager of the Sumerik
Operate.
Description of the module:
All NC-Programs, which are created with the Sinumerik Operate, are stored in the NC-work memory.
These programs can be accessed via the program manager for:
execution
alteration
copying
re-naming
deletion
The SINUMERIK Operate provides the following means of data transmission of NC-programs to
other storage media depending on the system components:
Its own hard disk (only 840D sl with PCU 50.x)
V.24-interface (with PCU 20 and PCU 50.2)
Floppy disk drive (only PCU 20 and PCU 50.2)
PCMCIA Card (only PCU 20)
Network connection
USB drive
