B611 Page 12 840D/828D SINUMERIK Operate
Notes
21. Program the following lines and end the program:
N310 REPEATB HOLES
N320 MCALL
N330 M25
N340 G0 X200 Z200
N350 M30
22. Start the simulation of the program.
Press the HSK 1.7 “Simulation” to open the simula-
tion window.
The control calculates the simulation and shows the
simulation in a side view.
To see the simulation of the machining from the front
of the blank, press the VSK 1.4 “Face view”.
Section 3
Complex programming example
