840D/828D SINUMERIK Operate
Mathematical principles
B504
1 Brief description
Aim of the module:
In this module you learn the mathematical approach necessary for the programming and for the cal-
culation of missing contour points.
Description of the module:
In this module contour points will be calculated using the Pythagorean theorem and trigonometrical
functions (sine, cosine and tangent).
