840D/828D SINUMERIK Operate Page 5
B500
B500
Notes
Turning Section 3
Unit
Machining
direction
Contour-
turning
(Metal re-
moval)
Planar
Longitudinal
Parallel to contour
From inside outward
From outside inward
From front to rear end
From rear end to front
BL
Raw material description (contour, cylinder; al-
lowance)
D
Cutting edge number
D
Maximum infeed depth (inc) mm
D1
(Thread)
First infeed depth mm
DA
Start-changing depth (inc)
DI
At 0 continuous cut
DIR
(parting)
Spindle rotation direction
counter-clockwise (CCW)
clockwise (CW)
DP
(Longitudinal
thread)
Infeed taper as a flank (inc)
DP
(Back-cut)
Distance of back-cut (inc)
DP is not displayed when N = 1
mm
DX
Maximum infeed depth (only parallel to contour
alternatively to D)
mm
DZ
Maximum infeed depth (only for parallel to con-
tour and UX)
mm
Limiting
Machining range limitation
Yes
XA: 1st limit XA Ø
XB: 2nd limit XB Ø (abs)
or 2nd limit referred to XA (inc)
ZA: 1st limit ZA
ZB: 2nd limit ZB (abs)
or 2nd limit referred to ZA
No
