Overview of System Error Alarms 03/2009
Number ranges of the alarm numbers
1-12
© Siemens AG, 2009. All Rights Reserved
SINUMERIK 840D sl, 840Di sl, SINAMICS, Diagnostics Manual (DAsl), 03/2009
SINAMICS alarms (faults/warnings)
Drive alarms
PLC alarms/messages
Tabelle 1-3 Number ranges of the message numbers, continued
201 000 - 203 999 Contro Unit
204 000 - 204 999 Reserved
205 000 -205 999 Power unit
206 000 - 206 999 Infeed
207 000 - 207 999 Drive
208 000 - 208 999 Option Board
209 000 - 209 999 Reserved
213 000 - 213 002 Lisense
230 000 - 230 999 DRIVE-CLiQ-component power unit
231 000 - 231 999 DRIVE-CLiQ-component encoder 1
232 000 - 232 999 DRIVE-CLiQ-component encoder2
233 000 - 233 999 DRIVE-CLiQ-component encoder 3
234 000 - 234 999 Reserved
235 000 - 235 999 Terminal module 31 (TM31)
236 000 - 236 999 Reserved
240 000 - 240 999 Controller Extension (NX32)
241 000 - 248 999 Reserved
249 000 - 249 999 SINSMICS GM7SM7GL
250 000 - 250 999 Communication Board (COMM BOARD)
250 500 - 259 999
Reserved
Tabelle 1-4 Number ranges of the alarm numbers, continued
300 000 - 399 999 Drive
Tabelle 1-5 Number ranges of the alarm numbers, continued
400 000 - 499 999 General alarms
500 000 - 599 999 Channel alarms
2)
600 000 - 699 999 Axis/spindle alarms
2)
700 000 - 799 999 User area
2)
800 000 - 899 999 Sequencers/graphs
2)
(810 001 - 810 009 System error messages from PLC
1)
)
