Siemens SIPROTEC 5 Technical Data

Dimensions of Device Rows
Type of
Construction
(Maximum
Dimensions)
Width over all x Height over all x Depth (incl. Current Terminal), Width and Depth
Each Rounded up to the Next Full mm (in Inches)
Type of construc-
tion
1/3 1/2 2/3 5/6 1/1
Flush-mounting
device
150 mm x
266 mm x
229 mm
(5.91 x 10.47 x
9.02)
225 mm x
266 mm x
229 mm
(8.86 x 10.47 x
9.02)
300 mm x
266 mm x
229 mm
(11.81 x 10.47 x
9.02)
375 mm x
266 mm x
229 mm
(14.76 x 10.47 x
9.02)
450 mm x
266 mm x
229 mm
(17.72 x 10.47 x
9.02)
Surface-
mounted device
with integrated
on-site operation
panel
150 mm x
314 mm x
337 mm
(5.91 x 12.36 x
13.27)
225 mm x
314 mm x
337 mm
(8.86 x 12.36 x
13.27)
300 mm x
314 mm x
337 mm
(11.81 x 12.36 x
13.27)
375 mm x
314 mm x
337 mm
(14.76 x 12.36 x
13.27)
450 mm x
314 mm x
337 mm
(17.72 x 12.36 x
13.27)
Surface-
mounted device
with detached
on-site operation
panel
150 mm x
314 mm x
230 mm
(5.91 x 12.36 x
9.06)
225 mm x
314 mm x
230 mm
(8.86 x 12.36 x
9.06)
300 mm x
314 mm x
230 mm
(11.81 x 12.36 x
9.06)
375 mm x
314 mm x
230 mm
(14.76 x 12.36 x
9.06)
450 mm x
314 mm x
230 mm
(17.72 x 12.36 x
9.06)
Expansion Module Dimensions
Type of Construction (Maximum Dimensions)
Width x Height x Depth, Width and Depth Each
Rounded up to the Next Full mm (in Inches)
Flush-mounting device 75 mm x 266 mm x 229 mm
(2.95 x 10.47 x 9.02)
Surface-mounted device with integrated on-site oper-
ation panel
75 mm x 314 mm x 337 mm
(2.95 x 12.36 x 13.27)
Surface-mounted device with detached on-site opera-
tion panel
75 mm x 314 mm x 230 mm
(2.95 x 12.36 x 9.06)
Plug-In Module Dimensions
Type of Construction (Maximum Dimensions)
Width x Height x Depth (in Inches)
USART-Ax-xEL, ETH-Bx-xEL 61 mm x 45 mm x 120.5 mm
(2.4 x 1.77 x 4.74)
USART-Ax-xFO, ETH-Bx-xFO (without protection
cover)
61 mm x 45 mm x 132.5 mm
(2.4 x 1.77 x 5.22)
ANAI-CA-4EL 61 mm x 45 mm x 119.5 mm
(2.4 x 1.77 x 4.7)
ARC-CD-3FO 61 mm x 45 mm x 120.5 mm
(2.4 x 1.77 x 4.74)
Minimum Bending Radii of the Connecting Cables Between the On-Site Operation Panel and the Base Module
Fiber-optic cable
R = 50 mm
Pay attention to the length of the cable protection
sleeve, which you must also include in calculations.
D-Sub cable R = 50 mm (minimum bending radius)
Technical Data
11.1 General Device Data
1112 SIPROTEC 5, High-Voltage Bay Controller, Manual
C53000-G5040-C015-A, Edition 05.2018

Siemens SIPROTEC 5 Specifications

General

Series	SIPROTEC 5
Communication Protocols	IEC 61850, DNP3, Modbus
Cybersecurity	Role-based access control, secure communication
Modular Design	Yes
Hardware Redundancy	Optional
Operating Temperature	-25°C to +70°C
Digital Inputs	Configurable, number depends on I/O modules
Digital Outputs	Configurable, number depends on I/O modules
Analog Inputs	Configurable, number depends on I/O modules
Current Transformer Inputs	Configurable, number depends on I/O modules
Voltage Transformer Inputs	Configurable, number depends on I/O modules
Time Synchronization	IRIG-B, SNTP, PTP
Protection Functions	Overcurrent, Differential, Distance, Over/Under Voltage, Frequency
Housing	19-inch Rack Mount
Dimensions	Depends on module configuration
Weight	Depends on module configuration
Voltage Input	24V DC, 48V DC, 110V DC, 125V DC, 220V DC, 250V DC
