Siemens SIPROTEC 7SJ61 - Register Addresses 10049 to 10064: Application Logic CFC

Modbus register map
7SJ61/62/63 6MD63 – Modbus
C53000-L1840-C001-01
6-10
Register
address
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10019 Input channel 19 (UsrSpO/O19) Single-point indication ON/OFF
–
10020 Input channel 20 (UsrSpO/O20) Single-point indication ON/OFF
–
10021 Input channel 21 (UsrSpO/O21) Single-point indication ON/OFF
–
10022 Input channel 22 (UsrSpO/O22) Single-point indication ON/OFF
–
10023 Input channel 23 (UsrSpO/O23) Single-point indication ON/OFF
–
10024 Input channel 24 (UsrSpO/O24) Single-point indication ON/OFF
–
10025 Input channel 25 (UsrSpO/O25) Single-point indication ON/OFF
–
10026 Input channel 26 (UsrSpO/O26) Single-point indication ON/OFF
–
10027 Input channel 27 (UsrSpO/O27) Single-point indication ON/OFF
–
10028 Input channel 28 (UsrSpO/O28) Single-point indication ON/OFF
–
10029 Input channel 29 (UsrSpO/O29) Single-point indication ON/OFF
–
10030 Input channel 30 (UsrSpO/O30) Single-point indication ON/OFF
–
10031 Input channel 31 (UsrSpO/O31) Single-point indication ON/OFF
–
10032 Input channel 32 (UsrSpO/O32) Tagging / internal single-point indication
ON/OFF
–
10033 Input channel 33 (UsrSpO/O33) Tagging / internal single-point indication
ON/OFF
–
10034 Input channel 34 (UsrSpO/O34) Tagging / internal single-point indication
ON/OFF
–
10035 Input channel 35 (UsrSpO/O35) Tagging / internal single-point indication
ON/OFF
–
10036 Input channel 36 (UsrSpO/O36) Tagging / internal single-point indication
ON/OFF
–
10037 Input channel 37 (UsrSpO/O37) Tagging / internal single-point indication
ON/OFF
–
10038
–
10048
reserved
4
–
6.4.2 Register addresses 10049 to 10064: Application logic CFC
Register
address
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10049 CFC-Output indication 1
(UsCfcSpO1)
Single-point indication ON/OFF,
released as CFC output
–
10050 CFC-Output indication 2
(UsCfcSpO2)
Single-point indication ON/OFF,
released as CFC output
–
10051 CFC-Output indication 3
(UsCfcSpO3)
Single-point indication ON/OFF,
released as CFC output
–
10052 CFC-Output indication 4
(UsCfcSpO4)
Single-point indication ON/OFF,
released as CFC output
–
10052 CFC-Output indication 5
(UsCfcSpO5)
Single-point indication ON/OFF,
released as CFC output
–
10054 CFC-Output indication 6
(UsCfcSpO6)
Single-point indication ON/OFF,
released as CFC output
–
10055 CFC-Output indication 7
(UsCfcSpO7)
Single-point indication ON/OFF,
released as CFC output
–
10056 CFC-Output indication 8
(UsCfcSpO8)
Single-point indication ON/OFF,
released as CFC output
–
4
For an as "reserved" labeled input status register the value 0 is always returned if reading.
