Modbus register map
7SJ61/62/63 6MD63 – Modbus
C53000-L1840-C001-01
6-22
Register
address
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10437 >Manual Close 1 = >Manual close signal 356
10438 >DataStop 1 = >Stop data transmission 16
10439 >Test mode 1 = >Test mode 15
10440 >Door open 1 = >Cabinet door open
–
10441 >CB wait 1 = >CB waiting for Spring charged
–
10442 >No Volt. 1 = >No Voltage (Fuse blown)
–
10443 >SF6-Loss 1 = >SF6-Loss
–
10444 Cntrl Auth (device 7SJ63/6MD63)
5
Control authority
(0 = REMOTE, 1 = LOCAL)
–
10445 ModeLOCAL (device 7SJ63/6MD63)
5
Control mode LOCAL
(0 = LOCKED, 1 = UNLOCKED)
–
10446 Cntrl Auth (device 7SJ61/7SJ62)
6
Control authority
(0 = REMOTE, 1 = LOCAL)
–
10447 ModeLOCAL (device 7SJ61/7SJ62)
6
Control mode LOCAL
(0 = LOCKED, 1 = UNLOCKED)
–
5
Not used in the 7SJ61 and 7SJ62.
6
Not used in the 7SJ63 and 6MD63.
