11SIPROTEC 7SJ80 / 7SK80 V4.6, Produktinformation
E50417-K1150-C342-A6, Ausgabestand 07.2010
Bild 3 Ansicht eines 7Sx80 von unten (Gehäusegröße 1/6)
Hinweis
Beim Schrankeinbau ist ein Montagewinkelsatz (enthält obere und untere
Winkelschiene) (Bestell-Nr. C73165-A63-D200-1) notwendig. Bei Ver-
wendung der Ethernetschnittstelle kann es notwendig werden die untere
Winkelschiene nachzuarbeiten.
