Siemens SIRIUS 3RR2242-1F.30 User Manual

Bestell-Nr. / Order No.: 3ZX1012-0RR22-1AA1 5
DE Einstellungen ES Ajustes TR Ayarlar
EN Settings IT Impostazioni РУ Настройки
FR Réglages PT Configurações
中文 设置
DE Anschließen ES Conexión TR Bağlantı
EN Connect IT Collegamento РУ Подсоединение
FR Branchement PT Conexão
中文 连接
2T1 / 4T2 / 6T3 / 14/22 / A2 B1 / B2 / Q / 32 / 31 / 34
3RR2241-1F.30 3RR2241-2F.30 3RR2241-1F.30 3RR2241-2F.30
PZ 2 (∅ 5 ... 6 mm)
0,8 ... 1,2 Nm
(7 to 10.3 lb in)
3RA2908-1A
∅ 3,0 x 0,5 [mm]
PZ 2 (∅ 5 ... 6 mm)
0,8 ... 1,2 Nm
(7 to 10.3 lb in)
3RA2908-1A
∅ 3,0 x 0,5 [mm]
2 x (0,5 ... 1,5) mm
2
IEC 60947: 2 x (0,75 ... 2,5) mm
2
max. 2 x (1 ... 4) mm
2
1 x (0,5 ... 4,0) mm
2
1 x (0,5 ... 4) mm
2
2 x (0,5 ... 2,5) mm
2
2 x (0,25 ... 1,5) mm
2
—
1 x (0,5 ... 2,5) mm
2
— 2 x (0,25 ... 1,5) mm
2
2 x (0,5 ... 1,5) mm
2
2 x (0,75 ... 2,5) mm
2
1 x (0,5 ... 2,5) mm
2
1 x (0,5 ... 2,5) mm
2
2 x (0,5 ... 1,5) mm
2
2 x (0,25 ... 1,5) mm
2
AWG
2x(20to12)
1x 12
1 x (20 to 12) 2 x (20 to 14) 2 x (24 to 16)
3RR2241-1FA30 3RR2242-1FA30
3RR2241-.F.30 3RR2242-.F.30
~10°
~10°
3RA2908-1A Ø 3,0 x 0,5 [mm]








0,5 mm
3 mm
10
10
10
