Operation
5
Siemens Building Technologies QSG_SISTORE_AX9_AX16_en.doc
Fire & Security Products 01.2004
2.2 Playback Commands
Camera Buttons (1 to 16)
Pressing a camera button will display that camera full screen.
Display Button
Pressing the Display button during playback will cycle the display through the
different screen layouts. The display modes are: full, 4 x 4 and 3 x 3, and 2 x 2 (4 x
4 format is not available for the SISTORE AX9). You cannot change the display
format while playing back video. Pause the video first, then change the format.
RW (Rewind) Button
Pressing the RW button plays video backward at high speed. Pressing the button
again toggles the playback speed from , and . The screen displays
, and respectively. Entering Fast Backward Playback mode from
Live Monitoring mode can be password protected.
PREV (Previous) Button
The PREV button only functions when playback video has been paused. Pressing
the PREV button plays video backward image-by-image.
Stop Button
Pressing the Stop button during Playback mode returns the DVR to the Live
Monitoring mode.
Next Button
The Next button only functions when playback video has been paused. Pressing
the Next button plays video forward image-by-image.
FF (Fast Forward) Button
Pressing the FF button plays video forward at high speed. Pressing the button
again toggles the playback speed from , and . The screen displays
, and respectively. Entering Fast Playback mode from Live
Monitoring mode can be password protected.
