Siemens SQL321B Series - Actuator Wiring Diagrams; SQL321.. Wiring Configuration; SQL361 B.. Wiring Configuration; SQL351 B.. Wiring Configuration

Siemens Smart Infrastructure 74 319 0809 0 M4520 2022-06-15 3 / 12
SQL321..
SQL361B25
SQL361B50
SQL351B25
SQL351B50
SQL361B150…
B6000
en
Accessory
zh-cn
附件
ASC10.21
SQL351B150…
B6000
c1
c2
Y
U
M
Y12
Y14
L
N
ASC10.21
ASC10.21
zh-cn
辅助开关
闭合
辅助开关
开启
控制信号(SQL361)
DC 0...10 V, 4…20 mA
(SQL351)
4…20 mA
位置反馈
DC 0...10 V
4…20 mA
测量中线
控制信号
关 (S)
控制信号
开 (O)
工作电压
AC 220V
系统零线
en
Auxiliary
switch
CLOSED
Auxiliary
switch
OPEN
Positioning signal
(SQL361)
DC 0...10 V, 4…20 mA
(SQL351)
4…20 mA
Position
feedback
DC 0…10 V
4…20 mA
Measuring
neutral
Control signal
CLOSED (S)
Control
signal
OPEN (O)
System poten-
tial
AC 220 V
Neutral
