DISPLAY INFORMATION
The OLED display shows you the center aiming circle, the unit of measure (Y), Angle Modified Range
mode (AMR) and the remaining battery status. The display will remain active for up to 10 seconds. You
can then press the RANGE button to determine range to target.
If you press the RANGE button while the rangefinder is off and continue to hold the RANGE button down,
the rangefinder will automatically switch into SCAN mode within 1 second.
After determining the distance to the target, the rangefinder will continue to display the center aiming
circle and range data for 10 seconds – and only the range data. All other information is not shown after
initial wakeup to prevent clutter in the field of view.
Center aiming circle
Range data
388.2
----
AMR
Y
Display at initial wakeup Display when ranging
