*Wire the AC input power to the AC output terminals.
2.4.6 Remote Monitoring
The M series inverter (produced after 2021 Nov) can be remotely monitored and controlled.
It supports 4 different types of remote monitoring
1. Plug in the remote LCD panel to the RS485 port.
2. Connects it to a computer via the USB port and monitor the inverter on the software.
3. Plugs a Wi-Fi or GPRS module into Wi-Fi port, monitor it on a computer or cellphone APP.
4. Connect to the RS485 port, it allows customer to monitor on their own software programmed with the
same protocol.
To monitor the inverter on a computer, please download the software (SG Solar Power Monitor) from our
website in the Support>Software Download section.
The M series inverters can be remotely monitored by a Wi-Fi or GPRS module plugged into its USB port.
The Wi-Fi / GPRS module is a plug-and-play monitoring device which allows users to monitor the status of
the PV system from a mobile phone APP or from the website anytime anywhere.
The inverter’s AC output power can be powered on and off via APP.
The Sigineer Monitor APP will automatically refresh the data in every 5 minutes. To access real date, please
roll down the screen to refresh.
To monitor the inverter via both WiFi and USB port, the RMT-WiFi module can be connected via a short
extension cable.
2.4.7 LCD & Specification Setup
Press the On/Off switch to turn on the unit.
The operation and display panel area includes three LED indicators, four function keys and a LCD display.
It shows very rich operating info.
1 LCD display 2 Status indicator 3 Charging indicator 4 Fault indicator 5 Function buttons
