SIGLENT UM0202X-E02C Service Manual

SDG2000X_ServiceManual_SM0202X-E01B.doc
17
Modulation Characteristics
Modulation
frequency
1m
1M
Hz
While modulation source is
“Internal”
Pulse width
deviation
resolution
6.67
ns
Burst Characteristics
Parameter
Min.
Typ.
Max.
Unit
Condition
Carrier
Sine, Square, Ramp, Pulse, Noise, Arb
Type
Count(1-1000000cycles), Infinite, Gated
Carrier
frequency
2m
BW
Hz
BW is the max. output frequency
Start/Stop
phase
0
360
°
Internal
period
1μ
1000
s
Trigger
source
Internal, External, Manual
Gated source
Internal /External
Trigger delay
100
s
Sweep Characteristics
Parameter
Min.
Typ.
Max.
Unit
Condition
Carrier
Sine, Square, Ramp, Arb
Type
Linear, Log
Direction
Up, Down
Carrier
frequency
1μ
BW
Hz
BW is the max. output frequency
Sweep time
1m
500
s
Trigger
source
Internal, External, Manual
Frequency Counter Characteristics
Parameter
Min.
Typ.
Max.
Unit
Condition
Function
Frequency, Period, Positive/Negative pulse width, Duty cycle
Coupling
mode
AC, DC, HFREJ
Frequency
range
100m
200M
Hz
DC coupling
10
200M
Hz
AC coupling
Input
amplitude
100mV
rms
±2.5 V
DC coupling, < 100 MHz
200mV
±2.5 V
DC coupling, 100 MHz ~ 200
