SIGLENT UM0202X-E02C Service Manual

SDG2000X_ServiceManual_SM0202X-E01B.doc
19
Auxiliary In/Out Characteristics
V
OH
3.8
V
I
OH
= –8 mA
V
OL
0.44
V
I
OL
= 8 mA
Output
impedance
100
Ω
Pulse width
500
ns
Frequency
1
MHz
Modulation Input
Parameter
Min.
Typ.
Max.
Unit
Condition
Frequency
0
50
kHz
Input
impedance
10
kΩ
Amplitude@
100%
Modulation
depth
11
12
13
Vpp
General Characteristics
Power
Parameter
Min.
Typ.
Max.
Unit
Condition
Voltage
100 - 240 Vrms (± 10%), 50 / 60 Hz
100 - 120 Vrms (± 10%), 400 Hz
Power
consumption
25.5
50
W
Dual channels, Sine, 1 kHz, 10
Vpp, 50 Ω load
Display
Parameter
Min.
Typ.
Max.
Unit
Condition
Color depth
24
bit
Contrast ratio
350:1
Luminance
300
cd/m
2
Touch panel
type
Resistive
Environment
Parameter
Min.
Typ.
Max.
Unit
Condition
Operating
temperature
0
40
℃
Storage
temperature
-20
60
℃
Operating
humidity
5
90
%
≤ 30 ℃
5
50
%
40 ℃
Non-operatin
g humidity
5
95
%
