Sigma BM40 - SPARE PARTS LIST TABLE; Component Details

Instruction manual BMC-40 -VVM-
17 of 19
SPARE PARTS LIST TABLE:
Position
Quantity
Code
Description
1
1
095016-A
Driven pulley BM-40
2
1
101022-5
Planetary shaft BM-60
3
1
101023-2
Driving bevel gear Z22 BMX-60
version with reduction gear
4
1
1
1
1
097201
Silkscreen printing BM-20
Timer
START/STOP button
ON/OFF switch
5
2
4
2
194021-1
194022-1
194023-1
Long grid wheel pin
Grid guide wheel
Short grid wheel pin
6
1
095020-2
Tool holder shaft BM-40
7
1
1
1
095058
095216
095217
Thin wire whisk BM-40
Cast blade BM-40
Cast spiral BM-40
8
1
095122-1
Bowl BM-40
9
1
095050-2
Bowl lifting rod BM-40
10
2
095049-3
Bowl lifting plate BM-40
11
4
095052-1
Plate distance pad
12
1
MARKET
Motor Gr.90 B14 for BM-40
13
1
095036-2
Cogwheel Z15
14
1
095008-9
Motor seat BM-40,BM-60
15
1
095208-1
Top casing BM-40
16
101181-1
2.5 module rack for BM-40
17
1
097013-4
Planetary pinion BM-20
18
1
101070-2 (50 Hz)
101017-3 (60 Hz)
Countershaft BM-60
19
2
095013-5
Variable semi-pulley BM-40
20
1
095080-3
Variator belt
33x10x1322
21
4
MARKET
38x42x15 bushes
22
1
095012-7
Variable pulley shaft BM-40
23
1
185016
Reduction gear support
24
1
185017
Reduction gear connection shaft
25
1
097016-3
Driven bevel gear Z22 M3
26
2
MARKET
Bearings 47-20-14 (6204)
27
1
MARKET
Bearings 30-62-16 (6206)
28
1
MARKET
Bearings 80-40-18 (6208)
29
2
MARKET
Bearings 52-25-15 (6205)
30
2
MARKET
Bearings 80-40-18 (6208)
31
2
MARKET
Bearings 62-25-17 (6305)
