SPARE PARTS LIST FOR PLANETARY MIXER BM60-BM80-BM100 DT
N° RIF. N° CODE DESCRIPTION QUANTITY
01 25009096 START button + code 25009093 + 25009094 1
02 25009094 Lift/Descent push button + 25009093 + 25009043 2
03 25007039 Timer + Knob 25007038 1
04 13000319 Ball bearing 6208 2RS 40-80-18 3
05 13000317 Ball bearing 6206 2RS 30-62-16 3
06 01101022 Planetary shaft for reducer 1
07 01101073 Variator belt 41,5x12x1419 1
08 13000326 Ball bearing 6305 2RS 25-62-17 2
09 01101017 Return shaft 60 Hz 1
01101070 Return shaft 50 Hz 1
10 01101016 Drive pulley 1
11 01101013 Variable half pulley 2
12 01101012 Variable pulley shaft 1
13 01101083 Variator spring upper cover 1
14 01101084 Variator spring lower cover 1
15 08101014 Variable pulley spring 2
16 08000001 Shock absorber 588434 700N 1
17 03101057 Upper cover 1
18 11001301 Motor G100 4P 2,2 Kw 230-400V/3 B5R (BM60DT) 1
11001302 Motor G100 4P 3 Kw 230-400V/3 B5R (BM80DT) 1
11001302 Motor G100 4P 3 Kw 230-400V/3 B5R (BM100DT) 1
19 14002822 Small foot M16 98/6364 1
20 25001301 Microswitch + lever 25001302 2
21 01095028 Round microswitch 1
22 01098108 Bowl blocking handle 2
23 01101019 Planetary 1
24 04101120 Bowl BM60 DT 1
04101156 Bowl BM80 DT 1
04101212 Bowl BM100 DT 1
25 01101148 Sleeve 1
26 05101160 Protection grid 1
27 01101149 Anti-unlocking ring 1
28 01101080 Tool shaft 1
29 13000311 Ball bearing 6200 2RS 10-30-09 4
30 01101077 Toothed crown for planetary 50 Hz 1
01101079 Toothed crown for planetary 60 Hz 1
31 01101020 Planetary pinion 1
32 01101018 Toothed crown 1
33 25009027 Net Lamp 1
34 25009097 STOP button + code 25009093 + 25009047 1
35 01101043 Bowl supporting arm 1
36 13000016 Ball bearing 6205 2RS 25-52-15 2
37 01101100 Bowl lifting screw 1
38 11000501 Motor G71 4P 0,55 Kw 400V/3 50Hz B14 1
39 01106025 Motor pulley Q18 1
40 12003301 Toothed belt SPZ 512 2
