Sigma ROX 9.0 - 2 INSTALLING THE SIGMA ROX 9.0 AND ITS ACCESSORIES; 2.1 INSTALLING THE BRACKET; 2.2 INSTALLING THE TRANSMITTERS - SPEED AND CADENCE; 2.3 INSTALLING THE MAGNETS - SPEED AND CADENCE

45
GB/USA
ROX 9.0
2.2 INSTALLING THE TRANSMITTERS – SPEED AND CADENCE
3Both
transmitters can be fitted with cable ties (permanent attachment)
or with the O-rings.
3To obtain the required gap of 12 mm or less, place the transmitter and magnet
closer to the hub.
2.3 INSTALLING THE MAGNETS – SPEED AND CADENCE
1 PREFACE AND CONTENTS OF PACKAGE
3Bracket 3Docking station
3Attachment
fittings
3Analysis
software CD
2 INSTALLING THE SIGMA ROX 9.0 AND ITS ACCESSORIES
Illustrations regarding to these assembly notes can be found in the enclosed folded sheets!
2.1 INSTALLING THE BRACKET
3Handlebars or front end
3Remove yellow f
ilm
1.2 CONTENTS OF PACKAGE
2.4 INSTALLING THE SIGMA ROX 9.0 TO THE BRACKET
5432
9876
13121110
20
161514
191817
SIGMA
DATA CENTER 1.0
SOFTWARE CD
