-10-

AMPLIFIER

BATTERY

20A

Red (#8 AWG)

Lights to be activated when

Slide Switch is in Position 3

PIN 8 - GRAY (#12-16 AWG) - L2

PIN 4 - YELLOW (#12-16 AWG) - S4

PIN 3 - ORANGE (#12-16 AWG) - L1

PIN 9 - WHITE (#12-16 AWG) - L3

PIN 7 - VIOLET (#12-16 AWG) - S1

PIN 1 - EMPTY

PIN 2 - EMPTY

PIN 5 - GREEN (#12-16 AWG) - S2

20A

PIN 6 - BLUE (#12-16 AWG) - S3

Lights to be activated by

Pushbutton Switch S1

Lights to be activated by

Pushbutton Switch S2

Lights to be activated by

Pushbutton Switch S3

Lights to be activated by

Pushbutton Switch S4

Lights to be activated when

Slide Switch is in Positions 2 & 3

Lights to be activated when

Slide Switch is in Positions 1, 2, & 3

Slide Switch Lights Pushbutton Lights

FUSE

Fuse the input wires at the

battery for the TOTAL amp

draw of all the lights combined

Signal LCS770 User Manual
