SIIG SuperSpeed USB 4-Port Hub - Package Contents; Layout; Device LED

2
Package Contents
• SuperSpeed USB 4-Port Hub
• USB 3.0 cable
• Switching power adapter
• Quick installation guide
Layout
Figure 1: Layout
• Device LED: Lit when a USB device is connected,
there is a Device LED for each downstream port
Downstream Port
(Type-A)
Downstream Port (Type-A)
Device LED
Power Jack
Upstream Port (Root port,
Type-B)
