SIKA Idroscan User Manual

SIKA Dr. Siebert & Kühn GmbH & Co. KG * Struthweg 7-9 * 34260 Kaufungen * Germany 3/9
℡ +49 5605-803-0 *  +49 5605-803-54 *  info@SIKA.net * www.SIKA.net
TECHNICAL DATA Ref R
(Idroscan)
RELATIVE PRESSURE (R) 1-2.5-5-10-20-40-50-60 bar
100-250-350-500 bar
700-1000-1500-2000 bar
LINEARITY and HYSTERESIS
≤ ± 0.20 % F.S.
TEMPERATURE INDICATION
a) Resolution
b) Class
0.1 °C
± 1 °C
INTERNAL RESOLUTION
READINGS PER SEC. (0 filter)
30.000 div.
10 (100ms)
REFERENCE TEMPERATURE
SERVICE TEMPERATURE
STORAGE TEMPERATURE
+23 °C
-10 / +70 °C
-10 / +80 °C
TEMPERATURE EFFECT (per 1°C)
a) on zero
b) on full scale
≤ ± 0.005%
≤ ± 0.005%
DISPLAY 16mm (custom LCD)
PROGRAMMABLE RESOLUTION
PROGRAMMABLE BAUD RATE
1, 2, 5, 10
38400, 19200,9600
DATA LOGGER FUNCTION 60000 points in step from 1s to 10 hours
ZERO FUNCTION
PEAK FUNCTION (Positive and Negative)
50% F.S.
125 Readings per sec. (8ms)
POWER SUPPLY
AUTONOMY
not rechargeable ALKALINE BATTERIES
BATTERIES
∼ 1 year
2x 1,5V size AAA
PROTECTION CLASS (EN 60529)
CASE
DIMENSIONS (HxLxW)
IP65
ALUMINIUM
128 × 84 × 29 mm
PRESSURE CONNECTION G ½’’
st. st. 1.4542
OPTIONALS
RUBBER COVER
SERIAL OUTPUT
RS232C CONNECTION
VACUUM scale
PVC
RS232C
Tank SUB D 9 pole FEMALE
-1/+1 -1/+2.5 -1/+5 bar
Pressure Positive Vacuum Resolution
1 bar 1.000 -1.000 0.001
2.5 bar 2.500 -1.000 0.001
5 bar 5.000 -1.000 0.001
10 bar 10.00 -1.00 0.01
20 bar 20.00 -1.00 0.01
40 bar 40.00 -1.00 0.01
50 bar 50.00 -1.00 0.01
60 bar 60.00 -1.00 0.01
100 bar 100.0 0.1
250 bar 250.0 0.1
350 bar 350.0 0.1
500 bar 500.0 0.1
700 bar 700.0 0.1
1000 bar 1000 1
1500 bar 1500 1
2000 bar 2000 1
