Siku 1 - Wiring Diagrams; Connection with Pull-Switch and Sensor; Connection without Pull-Switch; Connection with Run-on Timer Functions

Wiring diagram for the connection of a fan with a pull-
switch and with a movement sensor.
Wiring diagram for the connection of a fan with run-on
time / run-on time and humidity sensor and a pull-switch.
* Connect fans designed for 12 V power supply (indicated on the packaging and on the fan housing)
only to a 12 V power supply system!
Wiring diagram for the connection of a fan without a pull-
switch.
Wiring diagram for the connection of a fan with run-on
time / run-on time and humidity sensor and without pull-
switch.
