SIKU
X X X X X X X
Diameter of the outlet port - 100, 125, 150 mm
Fan series - SIKU 1, SIKU 2, SIKU 3, VKO, M, AZ, PF, LD, LD Auto, S, Silenta-S
Decorative front panel:
A - Brushed aluminium (for LD series)
N - Polished stainless steel (LD series)
Extra options:
Motor and impeller modifications:
V - With pull-switch
T - Fan with run-on time
T1 - Fan with start-up delay and run-on time
TH - Fan with run-on time and humidity sensor
TP - Fan with run-on time and movement sensor
AZ - Fan with automatic shutters
L - Ball-bearing motor
Turbo - High-performance motor
12 - Motor with 12 Volt nominal rating
Example designations:
100 AZTVL - Fan with 99 mm outlet port diameter, automatic shutter, run-on time, pull-switch, ball-bearing motor
150 AZTHL - Fan with 147.5 mm outlet port diameter, automatic shutter, run-on time, humidity sensor, ball-bearing motor
DESIGNATION EXPLANATION
