m) Fuse box
The fuse box is located under a protective lid, inside the seat compartment:
The scooter has 4 fuses, from left to right (from the driver’s point of view):
- F1 (Black): 1A fuse protecting the USB port
- F2 (Orange): 5A fuse protecting the 12V power source
- F3 (Grey): 2A fuse protecting the 60V power source
- F4 (Black): 2A fuse protecting the SEVCON
