FEATURE “C” PROGRAMMING
Turn the Ignition ‘switch ‘ON/OFF’ 3 TIMES and stay in OFF position.
Push the Valet switch 5 times (holding in on the 5th push) until one long chirp is heard then release the valet switch.
You are now in the Alarm feature “C” programming mode.
Press and release the transmitter button corresponding to the feature you want to program.
Press
Transmitter
Button
One Chirp / LED one pulse
Factory Default Setting
Two Chirps / LED
Two Pulses
Three Chirps /
LED Three Pulses
Four Chirps / LED
Four Pulses
1
Pink Wire =
Two Step Door Unlock
Output
Pink Wire = Factory
Security Disarm
Signal Output
Pink Wire = Start
Status Output
(Shock Sensor
Bypass)
Pink Wire = Start
Status Output
(Shock Sensor Bypass
20 SEC)
2
Override Without
Password Pin Code
Override With
Password 1-DIGIT
Pin Code
3
+
Gray Wire Channel 3 Output
= Pulsed output
Gray Wire
Channel 3
Output =
Latched output
Gray Wire
Output =
Latched Output
and Reset With
Ignition “ON”
Gray Wire Output =
Timer programming
(set to any interval
between 1 Second and
2 minutes.)
4 +
ADS Data Protocol Fortin Data Protocol
Exit: Turn Ignition to ‘ON’ position, or leave it for 15 seconds. 3 long chirps & 3 parking light ashes will conrm exit.
