SHUTDOWN DIAGNOSTICS
The unit has the ability to report the cause of the last shutdown of the remote start system.
Enter:
1. Turn the Ignition switch to “ON” position.
2. Press the button on the transmitter.
3. The LED will now report the last system shutdown by ashing for one minute in the following grouped patterns:
LED
Flashes
Shutdown Mode
1 (-) Safety Shutdown Input (Hood) 1. Close the hood.
2. Check H2/13 White/Black wire connection.
2
(+) Safety Shutdown Input (Brake) or
Neutral Safety Switch Input Fail.
1. Check H2/15 White/Violet wire connection.
2. Move the Enable Toggle Switch to “ON” position.
(If installed.)
3. Move the gear selector to “Park”/ “NEUTRAL” position.
3
No RPM or
Low Voltage.
Tachometer Checking Type:
Check H2/4 White/Red wire connection
Voltage Checking Type:
Program the “CHECK LEVEL” from
“Hi Check Level” to “Low Check Level”
4 Wait-to-Start Time Out Please check H2/20 White/Green wire connection
5 Over-Rev
6 System Timed Out
7 Transmitter
8 Tach. Signal Has Not Been Learned Re-learning the RPM (Start Feature E – 2 / 3)
