Silver Spring SC500-V3 - Parts List

Page 2Rev. 060518
DiscountRamps.com • 1-888-651-3431
Parts
Part Description Quantity
1 M14x2.0x30 Bolt
(use 7/8" or 22mm wrench) 2
2 M14x2.0 Nut
(use 7/8" or 22mm wrench) 2
3 M8x1.0x20 Carriage Bolt 2
4 M8x1.0 Lock Nut
(use 13mm or 1/2" wrench) 2
5 M10x1.5x30 Bolt
(use 17mm or 11/16" wrench) 2
6 M10x1.5 Nut
(use 17mm or 11/16" wrench) 2
7 M12x1.5x60 Bolt
(use 10mm Allen wrench) 1
8 M12x1.5 Lock Nut
(use 19mm or 3/4" wrench) 1
9 Pinch Bolt Assembly - M12x1.5x99 Bolt
(use 19mm or 3/4" wrench)
1
10 Hitch Pin Set 1
Part Description Quantity
11 Ramp Bracket 1
12 Reector with Mounting Screw 2
13 Double Spring Pull Pin with Handle 1
14 Single Spring Pull Pin with Handle 1
15 Rubber Handle Insert 5
16 12mm Pin with Clip 2
17 Anti-Tilt Locking Device
(use 17mm wrench) 1
18 Carrier Main Tube 1
19 Hitch Receiver Tube 1
20 Carrier Basket 1
21 Carrier Ramp 1
