SBTF 10 C3
■ 6
│
GB
│
IE
│
NI
Package contents (see fold-out page)
Bluetooth
®
Hands-Free Kit
Operating instructions
Ɣ Take the device out of the packaging and remove all
packaging materials.
Note:
Ɣ Check the package for completeness and for signs of
visible damage.
Ɣ If any items are missing or damaged as a result of
defective packaging or insufficient care during trans-
portation, contact the Service hotline (see the section
Service).
Technical data
Operating voltage/
current consumption: 12-24 V
/ 1000 mA
Bluetooth
®
Specification: Version 3.0 + EDR,
up to a range of 10 meters
Supported Bluetooth
®
profiles: HSP and HFP
Output voltage/
max. power via USB port: 5 V
/ 1 A
Fuse: F2AL / 250 V
Dimensions: approx. 16.2 x 5.5 x 2.3 cm
Weight: approx. 78 g
Operational temperature: +5° to +40°C
Storage temperature: 0° to +70°C
Humidity: 5 to 75%
(no condensation)
